Aegis series UPS is three phase on-line double-conversion UPS designed in small footprints with input power factor correction (Input PF≥0.99) and an enhanced output power factor to 0.9. It’s the ideal solution for critical information and telecommunication systems, network services. Aegis series UPS includes dual-mains input, automatic and maintenance bypass which make the system more reliable and easy to maintenance, moreover scalable runtime with flexible built-in/external batteries for increased availability.

Advanced dual-core DSP control technology and 3-level technology Active power factor correction (APFC), input power factor up to 0.99 System efficiency is improved to 95%, energy saving rate is doubled Output power factor 1.0 Dual input design, supporting independent bypass Advanced digital and parallel technology, providing higher reliability than single system Wide input voltage range 50 / 60 Hz auto-sensing frequency 50 / 60 Hz frequency conversion mode Work efficiency up to 98% in ECO mode Fan speed varies intelligently with load, reducing noise and extending its service life Conformal coating technology to make UPS operate in harsh environment for a long time Flexible battery configuration setting, selectable battery numbers: 32~ 40 pcs Digitally controlled charger (Max.10 A) Ability to switch on the UPS by battery in the absence of mains power (Cold start) Zero switching time for UPS power supply mode when the mains power is unstable, ensuring the output is uninterrupted Compact internal layout, small footprint 5 inches LCD colorful touch screen, friendly human & machine interface Powerful background software for parameters configuration and online upgrade Advanced multi-platform communication for UPS monitoring: RS232,USB,RS485,dry contacts, SNMP card,Wi-Fi card and GPRS card Linear derating in low voltage input, reducing battery discharging times, extending the service life of battery Intelligent battery management, automatic equalized and float charging control, charger dormancy control, improving the reliability of charger and extending the battery life Effective hardware and software protection, robust self-diagnosis function, abundant event log for future check Standard RS232,USB,RS485,EPO,Dry contacts,Parallel port Optional SNMP card,WI-FI card,GPRS card, SMS alarms

 Advanced dual-core DSP control technology and 3-level technology  Output power factor 1.0  Active Power Factor Correction Technology, input power factor up to 0.99  System efficiency improved to 96%, energy saving rate is doubled  Working efficiency up to 99% in ECO mode  Dual input design, supporting independent bypass  Advanced digital and parallel technology, providing higher reliability than single system  Wide input voltage range, 50 / 60 Hz auto-sensing frequency  50 Hz / 60 Hz frequency conversion mode  Compact internal layout, small footprint  Fan speed varies intelligently with temperature, reducing noise and extending its service life  Features strong fault tolerance, one fan damaged takes 50% of the load, two fans damaged take 30% of the load  Conformal coating technology to make UPS operate in harsh environment for a long time  Effective hardware and software protection, robust self-diagnosis function, abundant event log for future check  Linear downgrading in low voltage input reducing battery discharging times  Flexible battery configuration setting, selectable battery numbers: 30 ~ 44 pcs  Digitally controlled charger (Max.48 A )  Ability to switch on the UPS by battery in the absence of mains power (Cold start)  Zero switching time for UPS power supply mode when the mains power is unstable, ensuring output uninterrupted  Settable delayed start time when mains power is restored  5 inches LCD colorful touch screen, friendly human & machine interface  Powerful background software for parameters configuration and online upgrade  Advanced multi-platform communication for UPS monitoring: RS232, USB, RS485, CAN, RJ45, dry contacts, SNMP card, Wi-Fi card and GPRS card  Intelligent battery management, automatic equalized and float charging control, charger dormancy control, improving the reliability of charger and extending the battery life  Options and accessories: RS232, USB, RS485, RJ45, parallel, dry contacts, EPO and battery temperature compensation interfaces supplied; optional SNMP card, Wi-Fi card, GPRS card, battery temperature sensor, EMD detector and SMS alarms
